| Size: | 6.38″ x 1.77″ x 0.83″” |
| Weight: | 0.59lb |
| Output Voltage: | 12VDC & 24VDC |
| Output Current: | 5A x 1 Channel @ 12V | 2.5A x 1 Channel @ 24V |
| Output Power: | 120W |
| Output Ripple & Noise: | ≤400mV |
| Input Frequency Range: | 100 – 277VAC |
| Input Frequency Range: | 50 ~ 60Hz |
| Input Current: | ≤1.3A (120VAC) |
| Surge Current (Cold Start): | 75A @ 230VAC |
| Leakage Current: | < 0.75mA (240VAC) |
| Power Efficiency: | 88% |
| Working Temperature: | -22º ~ +122ºF |
| Storing Temperature: | -31º ~ +149ºF |
| Over-Current Protection: | Yes |
| Short-Circuit Protection: | Yes |
| Over-Voltage Protection: | Yes |
| Safety Rating: | IP67 |
| Warranty: | 5 Years |
