| Size: | 11.97” x 2.52” x 1.26” |
| Weight: | 2.75lb |
| Output Voltage: | 24VDC |
| Output Current: | 4A x 3 Channels |
| Output Power: | 288W |
| Output Ripple & Noise: | ≤600mV |
| Input Frequency Range: | 120 – 277VAC |
| Input Frequency Range: | 50 ~ 60Hz |
| Input Current: | ≤2.8A (120VAC) |
| Surge Current (Cold Start): | 46A @ 120VAC |
| Leakage Current: | < 0.95mA (240VAC) |
| Power Efficiency: | 92% |
| Working Temperature: | -13º ~ +122ºF |
| Storing Temperature: | -31º ~ +149ºF |
| Over-Current Protection: | Yes |
| Short-Circuit Protection: | Yes |
| Over-Voltage Protection: | Yes |
| Safety Rating: | IP67 |
| Warranty: | 5 Years |
